Product Details:
|
| Shaping Mode: | Blowing Mould | Product Material: | Plastic |
|---|---|---|---|
| Product: | Household Product | Product Name: | Making Mould |
| Design Software: | AutoCAD | Mould Life: | 250000-300000shots |
| Application: | Household Product Mold | Surface Treatment: | Polish. Etched. Texture |
| Mould Material: | P20/718/738/NAK80/S136/2738/2316 | Cavity: | Multi Cavity |
| Plastic Material: | ABS/PP/PS/PE/PVC/PA6/PA66.....etc | Surface Finish: | High Gloss Polishing |
| MOQ: | 1 Set |
| blowing mould raw material | mould steel P20,40Cr,4Cr13 |
| blowing product raw material | HDPE, PS, PVC, PET,PU,PE .,ETC |
| Mould time | 25-35 Days |
| Product time | 7-15 Days |
| Mould cavity | one cavity , multi-cavity or same different products be made together |
| Mould material | P20,2738, 2344,718,S136,8407,NAK80,SKD61,H13 |
| Runner system | Hot runner |
| Standard | HASCO, DME or dependent upon |
| Main technology | Milling, grinding, CNC,EDM, wire cutting, carving, EDM, lathes, surface finish, etc. |
| Software | CAD, PRO-E, Design time: 1-3days(normal circumstances) |
| Quality system | ISO9001:2008 |
| Establish time | 20days |
| Equipment | CNC,EDM,Cutting off Machine, plastic machinery, etc plastic part |
| Packing | Plastic bags, Cartons, wodden case,pallet , container,ect |
| product weight | 50-5000K |
<Blowing mould processing>
Blowing mould processing: Designing sample or drawing by software UG or pro/e, improving mold design with mold flow analysis, production after design confirming.
Applications: aviation, aerospace, Medical care,electronics, computers, machinery, ships, automotive industry, household appliances, communications, light industrial products, gifts, toys, plastic products, sports and leisure.
Blowing product processing: The extrusion blowing plastic process is consisted with five steps:
1. Plastic embryo (hollow plastic tube extrusion);
2. Close the valve mould on the embryo, clamp the mould and cut off the embryo;
3. Blow the mould to the cold wall of the cavity, adjust the opening and maintain a certain pressure during cooling;
4. Open the mould, remove the blowing parts;
5. Trim the flying edge to get the finished product.
Q: Does your company make mould by yourself?
A: Yes, we have more than 20 years mould manufacturer experience.
Q: How many kinds products can you make? Only make the mould?
A: We can make different kinds of mould, such as plastic injection mould, blowing mould, stamping mould, die casting mouldand silicone rubber mould. Besides, we also can produce the final parts for you.
Q: What’s the software you will use to check the drawing? And what’s format of drawing you can check?
A: Our designers and engineers all use AUTO CAD and Soliworks software to check 2D and 3D drawings.We can check the drawings with PDF, AI, DWG (CAD) and STP (3D) or IGS (3D) formats.
Q: Will you send me the free sample?
A: Yes, but you should charge the freight by yourself. We can return the fee if you place a bulk order.
Q: How to pack the moulds and products?
A: For moulds, we will be coated one-layer anti-rust oil first, and then also will be covered thin films on the mould, finally pack into non-fumigation wooden case. And as to products, we will pack into standard export cartons or as per customer’s request to pack.
Q:Your payment & shipment?
A:Payment:L/C, T/T; Shipment :DHL, TNT or by sea-shipment.
Q:Our port of shipment?
A:TianJin port.
Q:Type of shipping?
A:Traditionally , the port of departure is Tianjin Port. But We can also have a variety of modes of transportation, for example, we find a freight compay that can double customs clearance and deliver goods to the door. Customers can only save customs clearance costs,but also transport costs at the destination.
